Summary Traffic Analysis for
Telekom connections
| System: | SIX-Telekom-gw |
| Max Speed: | 400 Gbit/s |
The statistics were last updated Sunday, 18 May 2025 at 8:15
`Daily' Graph (5 Minute Average)
| Max | Average | Current | |
|---|---|---|---|
| In | 103.7 Gb/s (25.9%) | 42.2 Gb/s (10.6%) | 36.0 Gb/s (9.0%) |
| Out | 141.7 Gb/s (35.4%) | 50.4 Gb/s (12.6%) | 43.8 Gb/s (11.0%) |
`Weekly' Graph (30 Minute Average)
| Max | Average | Current | |
|---|---|---|---|
| In | 102.2 Gb/s (25.5%) | 44.1 Gb/s (11.0%) | 24.1 Gb/s (6.0%) |
| Out | 137.8 Gb/s (34.5%) | 53.1 Gb/s (13.3%) | 31.2 Gb/s (7.8%) |
`Monthly' Graph (2 Hour Average)
| Max | Average | Current | |
|---|---|---|---|
| In | 100.6 Gb/s (25.2%) | 43.2 Gb/s (10.8%) | 13.3 Gb/s (3.3%) |
| Out | 129.5 Gb/s (32.4%) | 51.6 Gb/s (12.9%) | 18.8 Gb/s (4.7%) |
`Yearly' Graph (1 Day Average)
| Max | Average | Current | |
|---|---|---|---|
| In | 106.3 Gb/s (26.6%) | 34.1 Gb/s (8.5%) | 42.2 Gb/s (10.6%) |
| Out | 198.7 Gb/s (49.7%) | 45.8 Gb/s (11.5%) | 52.0 Gb/s (13.0%) |
| GREEN ### | Incoming Traffic in Bits per Second |
|---|---|
| BLUE ### | Outgoing Traffic in Bits per Second |
| DARK GREEN ### | Maximal 5 Minute Incoming Traffic |
| MAGENTA ### | Maximal 5 Minute Outgoing Traffic |
